Atlassian ACP-610 Exam Practice Test Instant Access

Question 1

Your company recently created an internal IT project to track hardware requests. View the project configuration below: Project: Hardware request Project lead: Allen Frank Default Assignee: Project lead

To test the triaging process you create the first issue in the project and select the Macbook 13" component. You don t update the assignee field and leave it to the default value of Automatic.

Based on the current configuration, which value will the assignee field show after creating the test issue?

AAllen Frank

BMac Taylor

CAutomatic

DLouise Lin

EUnaligned

Answer : B

Based on the current configuration, the assignee field will show Mac Taylor after creating the test issue. This is because the Macbook 13' component has Mac Taylor as the component lead and the component/s field has been configured to override the project's default assignee when using a certain component.Therefore, when creating an issue with the Macbook 13' component, the assignee field will automatically be set to Mac Taylor, regardless of the default assignee of the project or the value of the assignee field before creating the issue34Reference:

3: What are components? | Jira Software Cloud | Atlassian Support

4: How to enable and edit component/s , affects Version/s and fix version ...

Question 2

Development team A is consistently overestimating the work they can complete per sprint. They want to be able to compare work committed and work completed in sprints over time. Which single report provides this information?

AControl Chart

BSprint Report

CCumulative Flow Diagram

DCreated vs Resolved Issues Report

EVelocity Chart

Answer : E

The Velocity Chart is the best report to compare work committed and work completed in sprints over time. It shows the average amount of work that a team can complete in a sprint, based on the historical data of previous sprints. It also shows how much work was planned and how much was actually completed in each sprint. By looking at the Velocity Chart, a team can see if they are overestimating or underestimating their capacity, and adjust their planning accordingly. Therefore, option E is correct.Reference:Velocity Chart,Managing Jira Projects Data Center and Server: Certification Bundle

Question 3

You just started working as a scrum master in the Engine team.

The first thing you do is to analyze the Velocity Chart of the team's scrum board as shown

AIssues not completed in Combo Sprint 3 were completed in Combo Sprint 4.

BCombo Sprint 1 has been deleted after it was completed.

CThere was a scope change during Combo Sprint 4.

DThe team only completed 2 out of 6 Story Points in Combo Sprint 3.

EAll issues in Combo Sprint 3 were estimated before the sprint was started.

Answer : C

The Velocity Chart shows the amount of work completed by a team in each sprint. The green area represents the completed work, and the gray area represents the estimated work. The difference between the green and gray areas indicates a scope change, which means that issues were added or removed from the sprint after it started. In Combo Sprint 4, we can see that the green area is larger than the gray area, which means that more work was completed than estimated. This implies that some issues were added to the sprint after it started, or that some issues were re-estimated with higher values. Therefore, option C is correct.Reference:Velocity Chart,Managing Jira Projects Data Center and Server: Certification Bundle

Question 4

Kim needs a single dashboard gadget that displays the following information for issues in her project:

* the total count of all issues

* the total count of each issue type

* the distribution of each issue type as a percentage

* a graphical chart display of that percentage

Which gadget meets this need?

AHeat Map

BTwo Dimensional Filter Statistics

CFilter Results

DIssues in progress

EIssue Statistics

Answer : E

The gadget that meets Kim's need is theIssue Statisticsgadget. This gadget displays the collection of issues returned from a filter, broken down by a field. Kim can configure the gadget to use her project as the filter, and the issue type as the field. The gadget will then show the following information for issues in her project:

the total count of all issues

the total count of each issue type

the distribution of each issue type as a percentage

a graphical chart display of that percentage

The other gadgets are not suitable because:

TheHeat Mapgadget displays issues from a project or filter, grouped by a statistic type, in a heat map format. Issues can be grouped by any statistic type (e.g. Status, Priority, Assignee, etc). However, this gadget does not show the total count of all issues, nor the distribution of each issue type as a percentage.

TheTwo Dimensional Filter Statisticsgadget displays issues from a filter in a table format, where each cell shows the number of issues for a given combination of two statistics types (e.g. Status vs Priority, Assignee vs Issue Type, etc). This gadget does not show the total count of all issues, nor a graphical chart display of that percentage.

TheFilter Resultsgadget displays the results of an issue filter on the dashboard. This gadget does not show any summary or breakdown of the issues by any field, nor a graphical chart display of that percentage.

TheIssues in Progressgadget displays all issues that are in progress and assigned to the user viewing the dashboard. This gadget does not show any information about other issues or issue types in the project, nor a graphical chart display of that percentage.

Question 5

You need to find all issues that were not competed in some past sprint, and that are now part of an active sprint. Identify two functions that you need to use in your JQL query. (Choose two.)

AclosedSprints()

Bfutures prints()

Ccompleted()

Dremaming()

EopenSprints()

Answer : A, E

The two functions that are needed to use in the JQL query to find all issues that were not completed in some past sprint, and that are now part of an active sprint are closedSprints() and openSprints(). The closedSprints() function returns all issues that are assigned to a completed sprint. The openSprints() function returns all issues that are assigned to an incomplete sprint. By combining these two functions with the NOT operator, we can filter out the issues that belong to both a completed sprint and an incomplete sprint, and only get the issues that were not completed in some past sprint, and that are now part of an active sprint. For example, the JQL query could be:

project = XYZ AND issuekey NOT IN (closedSprints() AND openSprints())

This query will return all issues in project XYZ that are not in both a closed sprint and an open sprint, meaning they are either in a closed sprint only or an open sprint only. Since we are looking for issues that are now part of an active sprint, we can assume they are in an open sprint only.Reference:Advanced search reference - JQL functions,Modifying closedSprints() to return previous two Sprints,JQL - Explanation of what closedSprints() does

Question 6

Your team uses Story Points for estimation and tracking.

You performed several actions in the active sprint.

Which two actions are reflected as scope change? (Choose two.)

AAdded a fix version on a committed story.

BEstimated a story in the backlog.

CDragged on estimated story from the backlog to the sprint.

DModified the estimate value on a committed story.

EAdded another 5ub-task to a committed story.

FLogged work on several committed stories.

Answer : C, D

The two actions that are reflected as scope change are dragging an estimated story from the backlog to the sprint and modifying the estimate value on a committed story. Scope change is a measure of how much work was added or removed from a sprint after it started. It is calculated by comparing the total story points committed at the start of the sprint and the total story points completed at the end of the sprint. If you add or remove issues from a sprint, or change their estimates, you are changing the scope of the sprint. The other actions mentioned in the question do not affect the scope of the sprint, as they do not change the amount of work planned or done in the sprint.Reference: Viewing the Velocity Chart, Scope change

Question 7

Your team works in a project that uses only one workflow, a simplified workflow.

The configuration of the corresponding Kanban board is shown:

Which statement is definitely true?

ABugs can be dragged from 'In Progress' to 'In Test' on this board.

BAll team members can transition issues from Backlog to In Test.

CIssues can be transitioned freely between all workflow statuses

DA resolution will be set once an issue is dragged to Done

Answer : A

The statement that is definitely true is that bugs can be dragged from ''In Progress'' to ''In Test'' on this board. This is because the board configuration shown in the image has two columns: ''In Progress'' and ''Done''. The ''In Progress'' column has three statuses mapped to it: ''To Do'', ''In Progress'', and ''In Test''. The ''Done'' column has one status mapped to it: ''Done''. Therefore, issues can be moved from one status to another within the same column by dragging them on the board. However, issues cannot be moved from one column to another by dragging them on the board, as this would require a workflow transition that is not available in a simplified workflow. A simplified workflow is a default workflow that allows any user with the Edit Issues permission to add or remove statuses on the fly. To move an issue from one column to another, you need to use the workflow button on the issue detail view and select a transition that matches the status of the destination column.Reference:Configuring columns, Using a simplified workflow
